| Type |
Indoor & outdoor full-color & single/dual color module |
| Scan mode |
Support 1-32 scan randomly and static |
| 1pcs of receiving card |
256W * 192H(suggest) |
| support areas |
largest: 1024W * 192H (single-dual color) |
| Receiving cards |
Receiving card set sequence randomly, it could recognize by automatically or by hand |
| connected ways |
| Gray Scale |
0-65536 |
| Smart set |
Smart set by few simple steps, through display routine setting, it could suit almost different PCB rouine |
| Play contents |
Play video, animation, picture, text, excel, PPT, time, counter etc |
| Test functions |
It have self test button, could test modes of red, green, blue, white, gray, oblique line, grid, spots etc |
| Time on/time off |
Time on/off display by defined and time on/off display by computer |
| Port |
2pin5V Power *1, 1000M Ethernet Port *2, HUB75B Port* 12 |
| Voltage |
3V-6V |
| Working temperature |
-30°c - 85°c |
