| Display type |
supports full-color, dual-color and single color led display |
| Display mode |
640*480 800*600 1024*768 1280*768 1280*800 1280*1024 1440*900
1440*1080 1600*1200 1680*1050 1728*1296 1920*1080 1920*1200
2048*1152 2048*1280 |
| Pixel |
802 sending card max supports 2048*640 |
| Cascade function |
Through the dig switch on 802 sending card, several 802 sending cards
can be easily cascaded to support a super large led display |
| Audio Transmission Function |
802 sending card sends audio data using network cable,
and Function board outputs audio signals to the display. Double 24bits
64KHZ hi-fi digital signal to analog signal or analog signal to digital signal,
making display have the perfect video effect. |
| Sending card rotation function |
In Sender setting, sending card has 0, 90, 180, 270 degree rotation function |
Sending card U/D port flexibility
for carrying half width or half height |
For example, TS801 can max support 1280*1024 with two ports |
| Sending card zoom in/out function |
In Sender setting, the ratio of width and height can be set to realize zoom in or zoom out |
| Multi-display synchronous and combination functions |
One sending card can control multi-displays, realizing displays combination, synchronous display, and independent play. |
| Supporting 10-bit colors |
The seventh supports 8-bit colors: 256*256*256=16777216 kinds of colors.
The eighth supports 10-bit colors: 1024*1024*1024=1073741824 kinds of colors.
It needs to work with our video processors using the 30 bits TTL. |
| Matching Software |
led studio V9.0 or above |
