Simply professional 4K scaling and switching.4K switching has never been more practical and straight forward. The modular VENUS X1 platform
allows the addition of a range of signal options over and above the standard inputs. Standard inputs
include 4K signals on Dual Link DVI, HDMI and DisplayPort. Output to DisplayPort as 4K or scale and
split across dual 2K DVI outputs. For those needing 4K distribution and splicing on four DVI, simply add
the additional output module. The output module expands VENUS X1PRO to four 2K DVI outputs and
adds a further DisplayPort output.
Alternately, VENUS X1PRO with the output module can be become a 4K presentation switcher with the
additional DVI outputs (and DisplayPort) becoming a full preview.
All the power and flexibility familiar with RGBlink X series
1.4K input support on DP, HDMI and DVI
2.Input standard 2K formats
3.Scale and switch seamlessly
between 2K and 4K inputs
4.Output to any format 2K or 4K
5.EDID management on board
6.HDCP 2.0 compliant
7.DisplayPort 1.1a with MST
8.Custom output resolution
9.Modular design
10.Options for expandability
11.Control your way either on board or with a range of
remote apps
